Ultima | Rear Brake Drum 254mm | Toyota Hiace 200 Series KDH TRH 106mm Bore 2005–2009 | AAP4106

Ultima Rear Brake Drum 254mm for Toyota Hiace 200 Series (106mm Bore) (Single)

The Ultima AAP4106 is a heavy-duty, OE-specification **Rear Brake Drum** designed specifically for the early models of the Toyota Hiace 200 Series with the 106mm centre bore (spigot hole). It ensures the reliable stopping power and durability required for light commercial vehicles.

Warranty

1 year / 20,000 km

Why Ultima?

Ultima brake drums are precision-engineered to match original equipment standards, providing a perfect fit and dependable braking performance under high-stress commercial use. They feature high-quality cast iron construction for effective heat dissipation and a long service life.

Key Features:

• Application: Rear Axle Brake Drum (Fits Left or Right side).
• Design: Standard OE Replacement Drum.
• Internal Diameter: **254mm** (10 inches).
• Centre Bore (Spigot Hole): **106 mm** (Crucial fitment detail).
• Stud Holes: 6 Bolt Holes.
• Material: Heavy-duty cast iron construction.
• Performance: Consistent and durable braking for Hiace vans/commuters.
• Unit of Measure: Sold individually (1 piece).

Technical Specifications

• Brand: Ultima
• Part Number (SKU): AAP4106
• System Type: Rear Brake Drum
• Design: Standard OE Replacement
• Position: Rear (Left or Right)
• Drum Diameter (Internal): 254 mm
• Overall Height (OAH): 72 mm
• Inner Height: 62 mm
• Centre Bore (Spigot Hole): 106 mm
• Studs: 6
• Bolt Circle Diameter (PCD): 139.7 mm
• Drum Wear Limit (Max Dia): 256 mm
• Vehicle Series: Hiace 200 Series
• Years: 2005–2009 (Check bore size)

Vehicle Fitment Information

Important Information

• The image shown may not reflect the actual product
• Shipping times may vary depending on destination and stock availability
• This drum fits either the Rear Left or Rear Right side. Please purchase 2 units for a complete axle replacement.
• **Critical Check:** Your vehicle must have a Rear Drum with a **106mm** Centre Bore/Spigot Hole for this part to fit correctly. The alternative is 107mm, which requires a different drum (e.g., AAP4150 or equivalent).
